Lumishore EOS-LUX Command Center

EOS-LUX Command Center

The key to controlling your LUX above-water lights and EOS underwater lights directly from your MFD, smart device, and/or optional Display.

Simple to set up and use, owners can control the lights by zone and create lighting scenes to match any mood. An input for “triggers” allows for programmable lighting events personal to you.

Simply connect the Command Center with a plug-and-play cable, and smart control for your lighting fixtures will appear automatically.

The Over-the-Air feature allows software updates for new features and improvements by connecting to a laptop or PC via Wi-Fi.

Required for all LUX above-water lights and EOS Series lights (excl. SMX93).

Features:

• Auto DJ automatically configures sensitivity and adjusts settings for optimal song transitions
• The control of your SUPRA lights through an interface module that connects to the SUPRA Hub’s data port
• Wi-Fi Hotspot allows you to control your lights from a smart device by connecting to the Command Center Wi-Fi, operating independently from the MFD (that can be turned off)
• Smooth Scene Transitions ensure a seamless experience when turning on your lights

Specifications:

• Supply Voltage Range: 10.5-31 VDC
• Max Current Draw 12/24V: 0.5A
• Reverse Polarity Protection: Yes
• Load Dump Protection: Yes
• ISO 8846 (Ignition Protection): Yes
• Ingress Protection Rating: IP67
